TY-1460W Spot UV Coater
MAIN FEATURES:
- Linear Rail Auto-Feeding
- 8,000sph Swing Delivery
- Dual-Roller Coating
- 1,200mm Auto-Stacking
- PLC Frequency Control
- 3-Lamp UV Curing
Technical Specifications
| Max. Sheet Size (L × W) | 1100 × 1460 mm |
|---|---|
| Min. Sheet Size (L × W) | 350 × 460 mm |
| Max. Coating Area (L × W) | 1090 × 1440 mm |
| Coating Registration Accuracy | ±0.15 mm |
| Coating Layer Thickness | 0.15 – 0.60 mm |
| Sheet Thickness | 105 – 600 gsm |
| Up to | 5,000 – 6,000 sheets/hour (Depends on paper size, dimensions and quality) |
| Power Required | 68kw/Water-based: oil-based total power |
| Machine Dimension (L × W × H) | 11,800 × 3,400 × 2,300 mm |
| Machine Weight | 10,200 kg |
See It in Action
Machine Highlights
Multi-functional Coating Oil Head
- Dual-roller differential-speed coating head ensures flat, uniform, and glossy oil film with precision. Optional ceramic anilox roller with chambered doctor blade configuration.
Electrical Control System
- Full-machine variable frequency drive (VFD) with PLC programmable controller ensures high stability and low failure rate.
Automatic Paper Collector
- Integrated auto-loading platform with maximum stack height of 1,200mm.
- Photoelectric pneumatic dual-side alignment system for precise stacking.
- Thin-paper guiding device guarantees smooth and orderly sheet delivery.
Paper Feeding and Printing Unit
- Swing-arm sheet transfer mechanism supports maximum speed of 8,000 sheets/hour. Impression and coating cylinders undergo precision grinding and dynamic balancing calibration for dimensional accuracy. Quick-mount system for coating cylinder blankets and plate bases, enabling fast plate changes.
Automatic Paper Feeder
- High-reliability suction heads with linear slide rails ensure fast paper feeding, tightly delivering sheets of all sizes.
- Sensitive electro-mechanical double-sheet detector automatically stops feeding upon detecting multiple sheets.
- Maximum paper stack height: 1,150mm.
- Precision front and side guides (front guide and pull guide) with quick-adjust mechanisms for accurate positioning.
UV Drying and Curing Equipment
- Three UV mercury lamps ensure rapid UV coating curing.
- Teflon mesh conveyor with bottom suction enables quiet, high- speed curing and maintenance ease.
- Full/half-lamp switching and UV leakage protection enhance safety.
- Integrated auto-temperature control, fault trip, and cooling/exhaust systems prevent overheating.
- Dual IR drying groups (12×1kW lamps, staggered layout).
- Auxiliary air-blowing guarantees uniform heat distribution.
Final Product Samples
Suitable for a wide range of premium packaging applications.
Installations Worldwide
Why Partner with FENGCHI?
Quality Assured
Manufactured by skilled technicians. ISO9001 certified quality management system. CE certified products ensuring international compliance.
Vast Experience
We find the right solution for your packaging production—from stand-alone machines to fully integrated turnkey systems. Customization is our strength.
50 + Patents
We continuously push the boundaries of speed and performance, securing 50 patents through independent research and development.
Global Support
11 service and support centers worldwide with around 50 sales agents. Local support on a global level. Direct technical support and parts department.
TY-1460W spot UV coater FAQs
The right machine starts with the right questions. If yours is not here, send us the job details and we will take it from there.
What is the smallest and largest sheet the TY-1460W can coat?
The TY-1460W takes sheets from 350 × 460 mm up to 1100 × 1460 mm (L × W), with a maximum coating area of 1090 × 1440 mm. Use the fit checker above to test your own blank.
How fast does the TY-1460W run?
Up to 5,000 – 6,000 sheets/hour, depending on paper size, dimensions and quality.
How accurate is the spot UV registration?
The TY-1460W holds ±0.15 mm registration accuracy, so a gloss area stays inside its printed target even on long runs.
What support and warranty are available?
FENGCHI provides installation guidance, operator training, and technical support worldwide. The standard warranty is 12 months from the shipping date and excludes misuse, accidental damage, and operator error. Paid service and spare-parts support continue after the warranty period.
Can I see this exact model running before I buy?
Yes. Ask us for working footage of the TY-1460W and we will send the machine you are actually buying, not a generic line video. You are also welcome to visit the factory and watch it run.
Can you customize machine specifications?
Yes. We offer OEM/ODM services and can customize machine width, speed, and features to meet your specific production requirements and material needs. Our R&D team works closely with customers to develop tailored post-press solutions for unique applications.
