Automatic Cardboard Laminator
Achieve ±0.5mm laminating accuracy at up to 9,000 sheets/hour. Built for folding carton and cardboard packaging manufacturers.
Automatic Cardboard Laminator
Achieve ±0.5mm laminating accuracy at up to 9,000 sheets/hour. Built for folding carton and cardboard packaging manufacturers.
GK-1210 Automatic cardboard laminator
Product Features
- High Precision
Digital control system with positional accuracy up to ±0.5 mm. - High Speed
Up to 9,000 sheets/hour to meet high-volume production needs. - Wide Compatibility
Front-suction feeder supports face paper down to 100 g/m² and backing paper down to 200 g/m². - Glue-saving Design
High-precision stainless-steel core-wrapped glue roller accurately controls adhesive application at 18 g/m², significantly reducing glue consumption while ensuring bonding quality.
Key Benefits
The fully automatic cardboard laminator designed for folding carton production. Engineered for high output, precision, and low operator workload.
High Output
Massive productivity up to 9,000 sheets/hour, ideal for high-volume cardboard, coated paper, and gray board laminating.
Servo Control System
±0.5mm high-precision laminating with full servo-driven system & digital operating panel. Automatic adjustment for consistent output.
Quick Job Changeovers
Switch between different sheet sizes and jobs in minutes, not hours, maximizing your machine uptime.
Heavy-Duty Construction
Both models feature robust construction with 6,500kg weight for stable, reliable operation.
Wide Compatibility
Top paper 100–700gsm, bottom paper 200–900gsm. Works with thin paper, cardboard, gray board, coated stock.
One-Key Automation
Input paper size & thickness → automatic feeding, laminating, stacking.
Technical Specifications
| Parameter / Model | GK-1210 |
|---|---|
| Max paper size (W×L) | 1200mm × 1100mm |
| Min paper size | 450mm × 350mm |
| Top paper thickness | 100 – 700 gsm |
| Bottom paper thickness | 200 – 1300 gsm |
| Max laminating speed | 7,200 sheets/hour |
| Laminating accuracy | ±0.5mm (standard sheet paper) |
| Applicable glue | Starch glue, resin glue, milky glue (PH Value 6-8) |
| Machine weight | 7000 kg |
| Machine size (L×W×H) | 9020mm × 2320mm × 2180mm |
| Input voltage | 380VAC / 3P |
| Power | 13 kW |
| Applicable paper | Thin paper, cardboard paper, coated paper, gray board, thick paperboard etc. |
Need a tailored specifications? Contact our sales engineers for custom configuration and site requirements.
Machine Highlights
Laminating Part
- The paper lamination alignment adopts differential speed tracking; the top and bottom papers are simultaneously conveyed to the alignment guide, ensuring accurate lamination.
Electric System
- Uses well-known components from both domestic and international brands, designed to meet CE standards, and supports remote control with equipment upgrades.
Feeding System
- Uses a 360-degree rotating high-speed front suction servo feeder equipped with a 4.0 kW vacuum pump to ensure faster, more stable paper feeding and smoothly handle both thick and thin papers.
Servo-controlled Stacking System
- Uses a servo control system that allows each lift or drop speed to be freely adjusted, ensuring stable, smooth, and seamless conversion.
Aligning System
- A full-servo tracking system ensures stability and achieves ±0.2 mm high-precision alignment.
Paper Collecting System
- Laminated paper is automatically stacked and transported via forklift, thereby reducing labor costs by 30% to 50%.
See It in Action
Watch the automatic cardboard laminator running at high speed in action.
Why Partner with FENGCHI
Quality Assured
Our quality management system is certified by ISO9001. Products manufactured by Fengchi are also certified by CE.
Vast Experience
More than 15 years of experience within automation gives us an enormous know-how and expertise in laminating solutions.
50 Patents
We continuously push the boundaries of speed and performance, securing 50 patents through independent research and development.
Global Support
We proudly export corrugated laminating solutions worldwide, ensuring international clients benefit from our innovative technology.
What Our Customers Say
“The machine runs very stably during long production shifts. Production efficiency improved significantly after installation.”
“We were looking for accurate laminating quality and lower labor costs. This machine achieved both.”
“The installation and training support were professional. The machine is easy to operate and highly efficient.”
Trusted by Industry Leaders Worldwide
Global Technical Support
After Sales service begins with the arrival of the machinery at the customer’s factory.
To maximize investment whether a single machine or an entire line, the equipment needs to enter the existing production quickly and deliver its contribution. Fengchi offers a dedicated team of technicians that assemble, calibrate and commission the machinery.
Our engineers teach customer operators the machines function, calibration, available options, best practice and scheduled housekeeping.
Fengchi is always available to its customers if they have a problem, concern or malfunctionwith their machinery.
Frequently Asked Questions
What industries use the GK-1210 cardboard laminator?
The machine is widely used in folding carton production, corrugated packaging, display board manufacturing, and commercial printing.
What materials can this machine laminate?
It supports cardboard, coated paper, gray board, thin paperboard, thick paperboard, and more.
Can the machine run continuously for industrial production?
Yes. The GK-1210 is designed for stable high-speed continuous operation in industrial packaging factories.
Do you provide overseas installation and support?
Yes. Overseas installation, operator training, technical support, and after-sales service are available.
How quickly can I receive a quotation?
Our sales team typically responds within 24 hours with pricing and machine recommendations.
How about warranty?
Warranty period: 12 months from the shipping date of machine. Warranty will be not valid if machine subject to misuse or accidental damage or operator’s error. During the valid time, we will supply spare parts. If you have any other questions, pls contact us and we will reply you through product’s photos and videos to make every detail clear. We also provide all lifetime warranty with paid service.
Do you have stock products to sell?
We produce machines in bacth normally. So most models we have some in stock, please check with us before ordering.
Will you supply for OEM orders?
Yes, we can customize the production machine according to your requirements.
