High-Speed Flute Laminator
Experience the industry’s most advanced full-servo high-speed flute laminator,
engineered to deliver 22,000 sheets/hour with precision ±0.5mm accuracy.
High-speed Flute Laminator
High-speed flute laminator for corrugated and cardboard packaging.
Why Choose GW Series Flute Laminator
Over 15 years of specialized innovation in corrugated laminating technology with 30+ patents and 25 dedicated engineers
High Throughput
22,000 sheets/hour maximum speed with 16,000 sheets/hour stable 24/7 production. ±0.5mm registration accuracy for consistent quality.
Operational Efficiency
2–5 minute job changeover with automatic feeding & stacking. Requires only one primary operator, drastically reducing labor costs.
Engineered for Longevity
Servo motors and drives built with 35% load reserve for 15+ years of consistent performance.
Global Support Network
24-hour remote response with 1-year comprehensive warranty and lifetime support options. CE certified for international safety standards.
Real Results from Real Customers
See how industry leaders are transforming their production with Fengchi
MicroPack Americas: 50-Year Packaging Leader
“We are extremely pleased and proud to have acquired the top flute laminator in China from Fengchi. It’s an exciting milestone for us to have the best in the industry.
I also want to extend my gratitude for the exceptional senitce and smooth negotiation process we’ve experienced. Congratulations to both our teams for this achievement!
Best regards.”
— Julio Miamau, CEO, MicroPack Americas
Production Impact
- Faster production cycles – Reduced time-to-market by 30%
- More consistent lamination quality – 99.8% quality acceptance rate
- Lower operating costs – 22% reduction in per-unit costs
- Enhanced competitive edge – Enabled new premium product lines
See Our Machine in Action
Real Results from High Speed Flute Laminator Production Line
Supports installation, training & spare parts. Global shipping available.
End-Use Applications
Find Your Perfect Model for Your Plant
Our GW-L Series high-speed flute laminators are engineered for different sheet sizes and production requirements
GW-1450L Flute Laminator
Model: GW-1450L
Membrane Material: Paper
Plastic Film Mulching Modes: Hot Laminating
Performance: Anticorrosive
Patent: Leading Edge Paper Feeding Patent
Stable Speed: 16,000 Sheets/Hour
Features: Fully Automatic, Intelligent, User-Friendly Design
Feeding Mechanism Features: Unique Servo Vacuum Paper Feeding
Advantages: Low Failure Rate, High Efficiency, Long Life
Transport Package: Standard Package
Specification: 16300mm * 2400mm * 2550mm
Trademark: Fengchi
Origin: China
After-sales Service: Engineers Available Video & Video conference Remote
Warranty: 1 Year
Classification: Post-Coating Laminating Machine
Application: Packaging Paper, Color Printing, Cardboard and Corrugated Laminating
Driven Type: Mechanical
Automatic Grade: Automatic
Customization: Available
GW-1700L Flute Laminator
Model: GW-1700L
Membrane Material: Paper
Plastic Film Mulching Modes: Hot Laminating
Performance: Anticorrosive
Patent: Leading Edge Paper Feeding Patent
Stable Speed: 16,000 Sheets/Hour
Features: Fully Automatic, Intelligent, User-Friendly Design
Feeding Mechanism Features: Unique Servo Vacuum Paper Feeding
Advantages: Low Failure Rate, High Efficiency, Long Life
Transport Package: Standard Package
Specification: 17300mm * 2400mm * 2650mm
Trademark: Fengchi
Origin: China
After-sales Service: Engineers Available Video & Videoconference Remote
Warranty: 1 Year
Classification: Post-Coating Laminating Machine
Application: Packaging Paper, Color Printing, Cardboard and Corrugated Laminating
Driven Type: Mechanical
Automatic Grade: Automatic
Customization: Available
GW-2200L Flute Laminator
Model: GW-2200L
Membrane Material: Paper
Plastic Film Mulching Modes: Hot Laminating
Performance: Anticorrosive
Patent: Leading Edge Paper Feeding Patent
Stable Speed: 16,000 Sheets/Hour
Features: Fully Automatic, Intelligent, User-Friendly Design
Feeding Mechanism Features: Unique Servo Vacuum Paper Feeding
Advantages: Low Failure Rate, High Efficiency, Long Life
Transport Package: Standard Package
Specification: 18500mm * 3050mm * 2880mm
Trademark: Fengchi
Origin: China
After-sales Service: Engineers Available Video & Videoconference Remote
Warranty: 1 Year
Classification: Post-Coating Laminating Machine
Application: Packaging Paper, Color Printing, Cardboard and Corrugated Laminating
Driven Type: Mechanical
Automatic Grade: Automatic
Customization: Available
* Need a tailored spec? Contact our sales engineers for configuration and site requirements.
Product Gallery
PU Bottom Feeding Wheel
- Unidirectional rotating feeding roller, without wear and tear, service life cycle up to 10 years.
Leading-edge Feed System
- Self-developed leading-edge feed system specially for deformed, warped corrugated papers.
One-button Operation
- Adopting 7-8 servo motors control systems, digital intelligent input, automatic order changeover in 2-3 min.
Automatic Lubrication of Bearings
- Intelligent control for automatic lubrication, no need for daily maintenance, saving labor costs, and improving production efficiency.
Enlarged Glue Roller
- Enlarged 150mm diameter stainless steel roller, laser engraved anilox, high-speed and stable without glue splashing.
Servo Control Lifting Pile Plate
- High speed feeder smooth feeding, single sheet lifting same as offset printing press, high efficient and stable.
Dual-bearing Structure
- Ensures efficient and stable operation of the machine with doubled life cycle.
Pre-stacking System
- Whole pallet loading platform, saving labor costs and time.
Shaft-less High Speed Feeder
- Servo controlled high-speed shaft-less feeder front-and-rear auto-adjustment.
Technical Specifications
| Parameter / Model | GW-1450L | GW-1700L | GW-2200L |
|---|---|---|---|
| Max Sheet Size (W x L) | 1450 x 1450 mm | 1700 x 1650 mm | 2200 x 2100 mm |
| Min Sheet Size (W x L) | 360 x 360 mm | 360 x 360 mm | 450 x 380 mm |
| Bottom Paper Sheet Thickness | F flute-10 mm | ||
| Upper Paper Sheet Thickness | 120 g-700 g | ||
| Max Working Speed | 22,000 Sheets/Hour (175 M/Min) | ||
| Laminating Accuracy (W x L) | ±1.0 mm (Standard Sheet Paper) | ||
| Applicable Glue | Resin adhesive, starch glue, etc. (PH6~8 will be suitable) | ||
| Power Supply | 380 VAC/3P | ||
| Power | 26 kW | 30 kW | 32 kW |
| Applicable Corrugated Board | A, B, C, E, F, 3ply, 5ply, 7ply corrugated board, and cardboard within above mentioned thickness range | ||
| Machine Weight | 8000 KG | 8500 KG | 9000 KG |
| Machine Dimension (L x W x H) | 15700 x 2400 x 2550 mm | 16300 x 2650 x 2550 mm | 18500 x 3050 x 2880 mm |
* Need a tailored spec? Contact our sales engineers for configuration and site requirements.
Why Choose Fengchi?
If you are looking for a reliable and fully automatic high-speed flute laminator, Fengchi is the right supplier for you.
Increase Productivity
By automating your corrugated laminating process, we deliver an accurate and consistent lamination, reducing waste and minimizing downtime.
15+ Years of Experience
More than 15 years of experience within automation gives us an enormous know-how and expertise in laminating solutions.
Reliable Solutions
We deliver reliable and easy-to-operate solutions of high quality that help our customers optimize their packaging line.
Installations Worldwide
We proudly export corrugated laminating solutions worldwide, ensuring international clients benefit from our innovative technology.
What Our Customers Say
Hear from industry leaders who have transformed their production with our high-speed automatic flute laminators
We are extremely pleased and proud to have acquired the top flute laminator in China from Fengchi. It’s an exciting milestone for us to have the best in the industry.
I also want to extend my gratitude for the exceptional senitce and smooth negotiation process we’ve experienced. Congratulations to both our teams for this achievement!
Best regards.
We have partnered with this company for years and have never been disappointed. Both the product quality and responsiveness of their service are outstanding. Every delivery meets our high standards, giving us a competitive edge in the market. They are truly a trustworthy partner.
I really like FENGCHI’s machines. These machines are easy to operate, and the finished products are very good.
Trusted by Industry Leaders Worldwide
Major Suppliers
Our Service for Your Success
Our service team ensures maximum production reliability and efficiency.
From mechanical and electrical assembly to performance calibration and operator training, our specialists ensure every piece of technology works flawlessly from day one. And with aftermarket support built on responsiveness and expertise, your uptime becomes our priority.
Whether you need parts, maintenance or digital remote support, we are here for you: sales@laminatorfc.com
Frequently Asked Questions
Why choose us to cooperate?
1. “FENGCHI” is well-known brand and paper flute laminator master in China since 2009, focus on solving the manufacturing process of over-gluing and laminating & stacking after the post-printing of color cardboard & corrugated cartons.
2. Strong R&D team by 25 senior engineers over 30 years experience in printing industry. With 30 patents to ensure product more stable, more efficient and durable.
3. After-sale service and technical assistance: company provides after sales service and technical assistance as per customers’ requirement and needs with response within 24 hours.
4.Cost saving: Full servo digital operating system greatly reduce operator level(normally two primary operator) with manpower saving, 150mm roller with double bearing and auto refueling system make equipment durable and free maintenance. China highest laminating speed at 22,000pcs/hour.
Are you a manufacturer?
Yes, we are Flute Laminator Master from China over 15 years, specialize in automatic flute laminators and flip flop stackers.
Do you have stock products to sell?
We produce machines in bacth normally. So most models we have some in stock, please check with us before ordering.
How about warranty?
Warranty period: 12 months from the shipping date of machine. Warranty will be not valid if machine subject to misuse or accidental damage or operator’s error. During the valid time, we will supply spare parts. If you have any other questions, pls contact us and we will reply you through product’s photos and videos to make every detail clear. We also provide all lifetime warranty with paid service.
How about installation and training?
Normally, one operator can finish intallation in 2 hours with installation manual and video. If purchaser’s engineer travels at own cost to China, free training session. If engineer sent to purchaser’s factory, all travel cost paid by purchaser.
Do you test all your goods before delivery?
Yes, we have 100% functional testing and pilot run before delivery to ensure product integrity. All products are certificed by CE.
What is your delivery time?
Our delivery time is 10-30 working days after receiving full payment or deposit. The specific delivery time depends on the product and the order quantity.
What are your packaging conditions?
Usually, we pack the machine in a container with a plastic bag with desiccants, then with strong seaworthy wooden cases. Each machine will be protected by anti-rusted oil before put into case.
Will you supply for OEM orders?
Yes, we can customize the production machine according to your requirements.
Ready to Transform Your Production?
Get your personalized proposal with a custom machine recommendation and detailed quote
Get Your Personalized Proposal
1. Share Your Requirements
Tell us about your production volume, sheet sizes, and specific challenges.
2. Receive Custom Recommendation
Our engineers will analyze your needs and recommend the optimal model.
3. Get Detailed Quote
We'll provide a comprehensive quote with delivery timeline and support options.
4. Schedule Live Demonstration
See the machine in action via live video demonstration from our facility.
